The Eaton EMAB04 24-Way Vertical Rackmount Managed PDU allows metering to the branch and phase level for effective load balancing, with no switching. The EMAB04 features remote site management and lets you turn off unused outlets to control commissioning. Additionally, the EMAB04 offers Phase Metering, Circuit Breaker Current Metering and Input Metering.
Phase: Single-phase
Nominal power: 3.84 kW
Nominal current: 16A
Input: IEC-60309 16A 1Ph
Output: (20) C13, (4) C19
- Features twenty (20) C13 outlets and four (4) C19 outlets.
- Remote Site Management
- Turn off unused outlets to control commissioning
- Phase Metering, Circuit Breaker Current Metering and Input Metering
- Circuit Breaker Status Monitoring
- Level 3 PUE measurements
- Outlet and IT Equipment Switching/reboot /sequencing across A and B feed in Daisy-Chain
- Sequence Outlets to avoid in-rush current, to ensure equipment starts in correct order
- Highly secure with user access control, password protection and SSL configurable to 1024 or 2048 bit
- Hot-Swap Control module with advanced LCD
- Optional Temperature/Humidity sensor (sold separately)
- Built-in IEC outlet eGrip retention, retains all standard IEC plugs
- Built-in outlet P-lock system, locking mechanism with P-lock power cords
Eaton G3 ePDU
